Re:New Race XC Wide MTB 29 Wheelset

$439 $679.00
35% off

We will ask for Axle info after checkout.

All import duties, taxes and handling costs are covered by us.

Order ETA 3-6 days*
Our wheels are in high demand, don't miss out. Order now.

*If shown in stock

Built for the demands of modern technical cross country racing.

29" | 24 Wide Int | 1517g

The Purpose

Building on everything we learnt with the XC Wide; the Race version takes things even further. Saving close to 150g whilst not sacrificing any strength, this is the perfect choice for when you're attacking both the ups, and downs, at race pace.

With 24mm internal 6069-T6 alloy (+69% tensile strength vs 6061-T6) rims they are no flexy featherweights- built to handle the demands of today’s rocky and rooty XC courses or be fitted to the new breed of long-legged “downcountry” bikes.

With 5° RapidEngage Hubs and excellent torsional strength from Pillar's PSR Straight Pull Spokes, they'll make every pedal stroke count when it's needed most.

The Purpose

Building on everything we learnt with the XC Wide; the Race version takes things even further. Saving close to 150g whilst not sacrificing any strength, this is the perfect choice for when you're attacking both the ups, and downs, at race pace.

With 24mm internal 6069-T6 alloy (+69% tensile strength vs 6061-T6) rims they are no flexy featherweights- built to handle the demands of today’s rocky and rooty XC courses or be fitted to the new breed of long-legged “downcountry” bikes.

With 5° RapidEngage Hubs and excellent torsional strength from Pillar's PSR Straight Pull Spokes, they'll make every pedal stroke count when it's needed most.

Key Features

Every detail maximised

  • Rims | 29". 6069 T6 (+69% tensile strength vs 6061-T6) sleeved construction, 24mm wide (internal), work-hardened shot-peened finish.
  • Hubs | 5° RapidEngage and H_CERAMIK coating for increased durability and strength. Large double sealed cartridge bearings. Boost (110/148) fitment with Rock Shox Torque Caps and Boost QR adapters (110/141) available. (We will fit the axles you need, just complete the simple form shown after checkout or add a comment in the notes section of the cart page). Hubs available with a 6-bolt disc mount or center lock option.
  • Spokes | 28 spoke count, straight pull PSR reinforced head Pillar spokes.
  • Tires | Optimised for 2.0"-2.3" tires set up tubeless, but also work very well with 2.20"-2.5". Also great with standard tires & tubes.
  • Axles | Oversized 7075-T6 heat-treated aluminium alloy axles.
  • Hand-built | All of our wheels are built and finished by hand, inclusive of a full quality control inspection.
  • Weight | 1517g (* Microspline freehub option will have an additional weight of 34g due to the additional bearing in the freehub).
  • See the full specs here

The Experts' View

Flow MTB Logo Singletrack Logo

Full Specs

  • Rims

    • 29" rim
    • 24mm internal width ideal for 2.0"-2.3" tire widths but also work very well with 2.0"-2.5".
    • 6069-T6 heat-treated aluminium alloy (+69% tensile strength vs 6061-T6)
    • Tubeless-ready – designed to work best with tubeless tires. Tubeless rim tape and valves included.
    • H-lock bead-seat up-kicks for easy and secure tubeless installation.
    • Matt black work-hardened shot-peened finish with laser etched graphics for superior durability.
  • Spokes

    • Straight-pull for excellent torsional strength and direct power transfer
    • 28 F&R spoke count. Laced 2 Cross.
    • Pillar Spokes made from Sandvik T302 (18/10) stainless steel.
    • Patented Pillar Spoke Re-enforcement, butted again just before the spoke head providing more durability in high stress area.
    • Black stainless treatment.
    • Nipples

      • Hard-anodized alloy for weight reduction and strength.
      • Square body for external adjustment and hex head for easy internal adjustment/tensioning.
      • Long 14mm thread for durability
      • 14 gauge
      • Black hard anodizing
    • Tires Info

      • Maximum tire pressure for this rim: up to 2.5" do not exceed 40psi. 2.6 - 3.0" - do not exceed 30psi. Please do not exceed the maximum pressure stated on your tire.
      • Designed to work perfectly with tubeless and non-tubeless tires.
      • Suitable tubeless MTB tire combinations from Schwalbe are available to be fitted to your Hunt Race XC Wheels.
    • Axle Size

      • Boost - 148x12mm (Rear) with 110x15mm (Front). 141x9mm (Rear) QR with 110x9mm (Front) QR adapters and Rock Shox Torque Caps available - just add a comment in the notes section on the cart page.
      • SRAM/Shimano 8/9/10/11 speed and SRAM XD compatible.
    • Front Hub

      • Asymmetric flanges for more balanced spoke tensions.
      • Oversized axles.
      • Extruded and CNC machined 6066-T6 heat-treated aluminium alloy body.
      • 7075-T6 aluminium alloy axles.
      • 6 bolt disc mount/center-lock option available.
      • Polished anodized black finish with laser graphics.
    • Rear Hub

      • Extruded and CNC machined 6066-T6 heat-treated aluminium alloy hub body.
      • 148x12mm.
      • H_CERAMIK freehub body reinforcement coating provides excellent durability and protects against cassette sprocket damage to the freehub often seen on standard alloy freehub bodies.
      • Boost QR skewers NOT supplied.
      • 4 pawl, 36 tooth RapidEngage freehub, with an engagement angle of just 5 degrees
      • Oversized 7075-T6 heat treated aluminium axles.
      • 9/10/11 speed Shimano/SRAM compatible freehub and SRAM XD Driver version available.
      • 7075-T6 aluminium alloy axles.
      • 6 bolt disc mount/center-lock option available.
      • Polished anodized black finish with laser graphics.
    • Bearings

      • Precision sealed cartridge replaceable units.
      • Large diameter ball bearings for extra durability.
      • Dual full-contact rubber seals.
    • Warranty, Support and Weight Limits

      A full 3 years from purchase date warranty is offered to the original purchaser only on all Hunt bike wheels against material or workmanship defects, please click here to read full details.

      All HUNT wheels models have to pass our harsh rolling-drum fatigue tests for rider weight limits, please see here for more details. Max system weight 297lbs (system weight – total weight of fully kitted up rider, bike and luggage). If a rider is over 273lbs then an experienced bike mechanic should check the wheel regularly and it is advisable to use tires at max 40psi as this will reduce the fatigue on the wheelset.

      Crash replacement 35% off plus All HUNT wheels models have been designed to meet the needs of the type of riding they are intended for. We are cyclists ourselves and do of course go above and beyond to offer excellent service if you ever do experience any issues. We carry full spares at very reasonable prices and offer complete support.

      60 Day Ride & Return Period. We are certain you'll be impressed by the acceleration, low-weight, speed and durability of our wheels. We are cyclists and as such strive to offer class leading service and support. Buy with confidence, if for any reason you wish to return the wheels for a full refund of your order you can do so up to a full 60 days after you receive them whether they have been ridden or not. Please note we cannot offer refunds on wheels that have suffered from crash damage but do offer a crash replacement discount.

      Reviews

      Bike Magazine and Website Experts' Views

      Singletrack Logo

      The result? There’s no doubt in my mind that the Race XC Wide is one of the smoothest wheelsets I’ve ridden

      "Proof that an all-metal wheelset can perform just as well on the trail, while even providing certain advantages... For those after a race-ready set of hoops that won’t shake your teeth out of your skull, the Race XC Wide is a killer option for the money."

      Singletrack Logo

      Hunt Bike Wheels introduces new sub-1600g Race XC Wide wheelset

      "To put it in perspective, that’s lighter than a comparable Stan’s No Tubes Crest MK3 wheelset (1579g claimed weight) or the Mavic Crossmax Pro (1580g claimed weight). It’s also a helluva lot lighter than Hope’s Fortus 23 wheelset (1845g claimed weight)."

      In the Box

      Contents

      • HUNT Black Shield PET high tensile strength tubeless tape fitted to wheels.
      • Cassette spacer for 8/9/10 speed
      • Tubeless Valves
      • Spare of each spoke plus nipples
      • Quality control card signed by your wheel builder

      We've got your back

      Rider Experience Support

      Unmatched rider support, 7 days a week. For quick and immediate access to all the help you need, try our Live Chat. Our team consists of real bike riders who are fully equipped to answer any questions and help out. See Contact Us page for more details.

      Spares Available

      Any spares for our wheelsets can be found on our website. If you assistance, contact us and we can help you.

      Next Day Shipping

      As enthusiastic cyclists, we know you want your bike gear so we make sure all in-stock items are packed and dispatched within 1 working day.* As soon as your order is dispatched you’ll receive an email notification.

      *Subject to stock levels & cleared payment

      60 Day Ride and Return

      These wheels come with H_CARE (Free Lifetime Crash Replacement) for the first owners. A full 3 years (4 years on CeramicSpeed bearings*) from purchase date warranty is offered to the original purchaser only on all HUNT wheels against material or workmanship defects. Read more here.
