HUNT Sprint CeramicSpeed Hub Set
Front Only 20h - Limited Stock
Rear Only 24h - Limited Stock
Hub Set (Front 20h/Rear 24h) - Limited StockItems are selected to ship from us in the week stated. Delivery time is 2-6 days*
We will ask for Axle info after checkout.
All import duties, taxes and handling costs are covered by us.
Order ETA 3-6 days*
Our wheels are in high demand, don't miss out. Order now.
*If shown in stock
For Road/TT/Tri on-road use. Geared toward riders looking for maximum efficiency and reduced rolling resistance.
346G (pair) | 7.5 deg engagement angle | 20h Front/24h Rear
The Purpose
The HUNT Sprint hub forms the bedrock of our top performing HUNT Wheels. Designed to offer ultra-fast engagement, consistent reliability, durable construction, and low friction bearings, all in a lightweight package. With high-grade 6061 T6 forged and machined alloy shell construction, multiple bearing options, and a proven leaf and pawl system that provides an engagement angle of 7.5 degrees without sacrificing reliability or adding unneeded weight, the HUNT Sprint hub has been meeting and exceeding the needs of road and gravel riders of all levels for years.
CeramicSpeed is known for creating the highest performance bearings available. We’ve partnered with CeramicSpeed to create the fastest complete wheel systems since the debut of our LIMITLESS technology. CeramicSpeed bearings are chosen for their low rolling resistance and are chosen by the top international athletes and teams. These bearings last 10X longer than typical stainless bearings.
For a full comparison of our bearing packages, read This Guide.
Technical Features
- 6061 T6 alloy construction
- Engagement angle of just 7.5°
- 3x Leaf-sprung, treble-tooth pawls
- 48 tooth drive ring
- Steel Spline freehbub body reinforcement insert provides excellent durability against cassette sprocket damage to the freehub often seen on standard alloy freehub bodies.
- 15mm diameter hub axles, made from 7075 alloy with circular dropout interface steps adds stiffness
- Front hub: 105 grams. 20-hole
- Rear hub: 241 grams, 24-hole
- Centerlock disc rotor interface
- Polished anodized black finish with laser graphics
- Measurements for wheel building
The Purpose
The HUNT Sprint hub forms the bedrock of our top performing HUNT Wheels. Designed to offer ultra-fast engagement, consistent reliability, durable construction, and low friction bearings, all in a lightweight package. With high-grade 6061 T6 forged and machined alloy shell construction, multiple bearing options, and a proven leaf and pawl system that provides an engagement angle of 7.5 degrees without sacrificing reliability or adding unneeded weight, the HUNT Sprint hub has been meeting and exceeding the needs of road and gravel riders of all levels for years.
CeramicSpeed is known for creating the highest performance bearings available. We’ve partnered with CeramicSpeed to create the fastest complete wheel systems since the debut of our LIMITLESS technology. CeramicSpeed bearings are chosen for their low rolling resistance and are chosen by the top international athletes and teams. These bearings last 10X longer than typical stainless bearings.
For a full comparison of our bearing packages, read This Guide.
Technical Features
- 6061 T6 alloy construction
- Engagement angle of just 7.5°
- 3x Leaf-sprung, treble-tooth pawls
- 48 tooth drive ring
- Steel Spline freehbub body reinforcement insert provides excellent durability against cassette sprocket damage to the freehub often seen on standard alloy freehub bodies.
- 15mm diameter hub axles, made from 7075 alloy with circular dropout interface steps adds stiffness
- Front hub: 105 grams. 20-hole
- Rear hub: 241 grams, 24-hole
- Centerlock disc rotor interface
- Polished anodized black finish with laser graphics
- Measurements for wheel building
The Details
Materials
HUNT Sprint hubs start as a block of aerospace grade 6061 alloy. After cold-forging and pressing the material into the rough hub shape, they go through a T6 heat treatment to make them stronger. This process aligns the grain structure, and reduces machining time and waste.
The hubs are then machined and anodized, before machining again, to get the bearing faces to the required tolerances. Within the shell, we use a 15mm diameter axle made from 7075-T6 alloy, offering incredible yield strength and UTS (Ultimate Tensile Strength).
Bearings
The Sprint hub system features four bearings in the rear hub and two in the front, each spaced as far outboard as possible in the shell for lateral rigidity. We offer riders multiple high performance bearing options to best suit their terrain, riding conditions, and preferences.
Freehub Details
For our freehub systems, we strive to deliver the features that matter most to the rider. We utilize a tried and true, easy to maintain leaf-sprung, treble tooth three-pawl driver mechanism that is constructed from 7075-T6 alloy. The hardened steel three-tooth pawls engagement that mesh perfectly with our 48-tooth drive ring, mounted into the hubshell. Upon engagement the system provides an engagement angle of just 7.5°. For the rider, this system transfers pedaling input immediately, whether you’re powering up a steep climb or sprinting through the final turns of a criterium. There is also a Steel Spline Insert re-enforcement to excellent durability against cassette sprocket damage often seen on standard alloy freehub bodies.
Same Performance, Less Noise
Our hubs have a brilliant, yet subtle buzz when coasting. A lot of variables can affect the acoustics when you begin to coast, including the volume of air space in the hub, the thickness of the hub shell, the number of engagement points, the stiffness of the leaf springs, the level and type of lubrication, as well as the speed at which you are coasting. Based on rider feedback, we have refined our “buzz” with a set of pawls installed with slightly rounded off tips and also a set of leaf springs which have a softer preload. The result is a quieter, but not silent, ride when you begin coasting. Learn more about freehub sound from the experts at GearPatrol.
Proven in Competition
Sprint hubs have sat at the heart of our road performance wheels for years, and have been validated at every level of racing, including Grand Tour stages victories, one-day classic podiums, national titles, countless classification jerseys, and all types of racing in between.
Specs
- Weight: 105-gram front, 241-gram rear, 346-gram pair
- Engagement Angle: 7.5 Degrees
- Engagement Angle: 15mm Diameter 7075 alloy high- strength axle
- Axles: 3x Leaf-sprung, treble-tooth pawls, 48 tooth drive ring.
- Spoke Holes: 20 Front, 24 Rear
- Freehub Options: Shimano HG, XD/XDR, Campagnolo, Campagnolo N3W (Ekar)
- Disc Rotor Interface: Centerlock (6-bolt adapters available separately here)
Validated By The The Experts
 |
Tyler Benedict - BikeRumour“For a road wheelset, 7.5º is on the quick side, and I appreciate this. There’s less lag when resuming pedaling from a coast, and it gives the wheels a higher-end feel…more polished.” - (44 Aerodynamicist) |
 |
Stu Kerton - Road.cc“Pick-up from the pawls in the freehub is instantaneous, which removes any slop when you hammer on the pedals from a standing start or when exiting a tight corner that you've freewheeled through.”- (48 Limitless) |
 |
Ashley Quinlan – BikeRadar“The hubs feel smooth and efficient, taking a satisfyingly long time to spin down when wound up on a service stand.”- (48 Limitless UD) |
